Dope-dyed para-aramid fibers

Extreme collision and iterative upgrade. Delicate and tough fiber bears the exploration and innovation of fiber practitioners.Benefited from the cross of fiber boundary,breakthrough of limit, perfect fusion with the extreme, and the collisions to gain endless possibilities and

amazing charm, each strand shows exquisite skills and ingenuity to realizie hard core protection. Fiber hasbecome more and more lighter, stronger, tougher and resistant to high temperature,

facilitating its use in anti-cutting clothing, shoematerials, fire-fightingclothing, flight clothing,military equipment, urban light box cloth, fluedust removal, wind power blades, aerospace and

other fields. Fiber shows its best accompanying in extreme details and high value in extreme environments.

EXTREME UPGRADE

SPECIAL FIBERFORSHOES ANLOTHING

Shoes and clothing are made from special fibers,foreseeing the future with excellent performance.The high cut resistance of carbon fiber and the

high toughness of ultra-high molecular weight polyethylene fiber are perfectly combined to create cut-resistant ultra-high molecular weight

polyethylene fiber products which can effectively shield us from accidental scratches at work,maximizing protection and comfort.PBT/PA6

skin-core composite monofilament, combining the strength and stiffness of polyester with the abrasion resistance and moisture absorption of

nylon, can provide excellent support for shoe upper proprietary materials. Fine denier polyimide fibers, in-situ coloring of para-aramid pioneered

for apparel applications, bringing disruptive experiences to special wear scenarios.para-aramid.

Dope-dyed para-aramid fibers

Recommendation Reasons

While maintaining the original excellent properties of aramid fibers, it has high strength, flame retardant and temperature-resistance property, and can be customized with bright and rich colors. It has a very broad market demand and application prospect in the fields of military and high-end digital product protective cases and so on.

Processing Technology

The color paste is added to the para-aramid fiber spinning dope, and then fed through the spinneret, extruded into the coagulation bath for spinning. Finally, the produced fibers are washed and dried.

Characteristics of Fiber and Product

Main Specifications

Staple Fibre: 1.65~2.53dtex/38mm~51mm

Filament: 220~3300dtex/90~2000f

Standards and Certifications

Para-aramid Fiber (1414)Filament Yarns (FZ/T 54076-2014)

Fiber Performance and Product Features

. High strength, high tenacity and high tensile strength the tensile

strength is 5~6 times higher than that of steel wire, and the specific

tensile modulus is 2~3 times higher than that of steel wire, while the

density is only about 1/5 of steel wire

. Stock-dyed, green and environmentally-friendly, colorful, not easy to fade

. High and low temperature resistant

. Intrinsically flame retardant, with the limit oxygen index of 29%

Specifications	Tensile strength (g/D)	Maximum load (N)	Chord modulus (g/D%)
1100dtex/667f	23.1	232.0	680.0
Elongation at break(%)	Water content (%)	0il content (%)	Color fastness(Grade)
3.5	6.4	1.0	4-5

The downstream application guidance

Spinning: Staple fiber can be spun purely or blended with other fibers

Weaving: Filament yarns can be used directly for knitted and woven fabrics; can be made into twisted threads and sleeves

Terminal field	Raw material ratio	Count	Main products and properties
Home textiles	70% para-aramid fiber, 30% pre-oxidized fiber	40s	Flame-retardant, abrasion-resistant and cut-resistant; can be used for door curtains and carpets for special requirements
Specification	50% para-aramid fiber, 45%dacron, 5% static wire	60s	Abrasion-resistant; can be used in joint areas of outdoor clothing
3C protective cases	Various para-aramid fiber filament yarn	600D&800D或 1500D	Lightweight, abrasion-resistant, impact-resistant,slip-resistant
Flight clothing	93% meta-aramid fiber, 5% para-aramid fiber,2%static wire	50S/2	Flame retardant, warmth, high strength
Building reinforcement	100% para-aramid fiber	3000D	Reinforcement of tunnels and buildings with insulation requirements

Fiber Application

Clothing textiles：Safety protection suit,Professional sportswear,Garment lining

Home textiles:Filler

Industrial textiles:Fire supplies,Filtration products,Specialty Paper

Military textiles,Battery separator,Sporting goods,Building enhancement,TAPS,Engine shell,Cable

Q: Do you know the excellent properties and the widespread application of dope-dyed para-aramid fibers?

A: With the natural color of golden yellow, para-aramid fiber has high

strength, high modulus, outstanding heat resistance and good stability. Lt has a shrinkage rate of 0 at 150℃ and can maintain high strength at high temperature. For example, 65% of the original strength can be maintained at 2600.The development of dope-dyed para-aramid fiber can meet the needs of personalization and special fields. For example, it can be made into woven fabrics and combined with resin to produce 3C protective cases and sports equipment, and can be made into yarns to produce combat uniforms, flight clothings and firefighter uniforms.
