High-modulus Recycled Polyester Industrial Yarn

Reasons for recommendation

Made from 100% recycled polyester material, the fiber has high

strength and good dimensional stability, providing sustainable fiber

raw material support for automotive rubber frame products such as

builder fabrics and coil hoses, as well as ropes and frame materials.

Preparative technique

The fiber is prepared by high-oriented spinning technology and

low-draw post-treatment process using recycled polyester chips

from solid state polycondensation technology.

Features of fibers and finished products

Main Specifications

Filament: 1100dtex/320f, 1440dtex/384f,1670dtex/480f

Relative Standards

Polyester filament for industry(GB/T 16604-2017)

Technical specification for eco-design product assessment-recycled polyester (FZ/T07015-2021)

Properties of fibers and features of finished products

·Made from 100% recycled polyester, and is green and

environmentally friendly.

·high strength, high modulus, low tensile deformation under

external force, comparable originalquality.

·Good dimensional stability,chemical resistance,and abrasion

resistance.

Performance indexes of high-modulus recycled polyester industrial yarn

Specifications	Breaking tenacity (cN/dtex)	Elongation at break(%)	Initial modulus (cN/dtex)	Constant load elongation(%)	Dry thermal shrinkage (%)	Strength retention after thermal aging (180℃24h, %)
1100dtex/320f	≥6.80	12.0±2.00	110	5.2±0.80	3.00±0.50	≥90

The downstream application guidance

Co-twisting: Two or more of its strands can be twisted into cords, and it can also be mixed with other fibers into coil hoses, ropes, among others.

Weaving: The fiber is mainly arranged by a certain warp density in a plain structure to make cord fabrics and gray cloth; it can also be used for the development of webbing and other cloth covers.

Impregnation: It can be made into cord fabrics by specific impregnation treatment and certain thermal stretching and setting process, and can be vulcanized and bonded with rubber.

Examples of downstream applications of high-modulus recycled

polyester industrial yarn

The downstream application guidance

Co-twisting: Two or more of its strands can be twisted into cords, and it can also be mixed with other fibers into coil hoses, ropes, among others.

Weaving: The fiber is mainly arranged by a certain warp density in a plain structure to make cord fabrics and gray cloth; it can also be used for the development of webbing and other cloth covers.

Impregnation: It can be made into cord fabrics by specific impregnation treatment and certain thermal stretching and setting process, and can be vulcanized and bonded with rubber.

Examples of downstream applications of high-modulus recycled

polyester industrial yarn

Types of Fabric	Raw material ratio	Fiber specification	Main products and properties
Cord fabrics	99% warp: high-modulus recycled polyester industrial yarn/1% weft: Core-spun yarn	1100dtex/320f1650dtex/384f1650dtex/480f	Used in tire cord fabrics, with high strength,low elongation, and good dimensional stability
Coil hoses	100% high-modulus recycled polyester industrial yarn	470dtex/160f550dtex/160f	For automotive rubber products with high strength,high adhesion and good fatigue resistance

Examples of downstream applications of high-modulus recycled

polyester industrial yarn

Types of Fabric	Raw material ratio	Fiber specification	Main products and properties
Cord fabrics	99% warp: high-modulus recycled polyester industrial yarn/1% weft: Core-spun yarn	1100dtex/320f1650dtex/384f1650dtex/480f	Used in tire cord fabrics, with high strength,low elongation, and good dimensional stability
Coil hoses	100% high-modulus recycled polyester industrial yarn	470dtex/160f550dtex/160f	For automotive rubber products with high strength,high adhesion and good fatigue resistance

Application of fibers

Industrial textiles：Automotive interior/Outdoor products/Rubber product

Q: What are the specific applications of high-modulus recycled polyester

industrial yarn in the automotive industry?

A:With increasing demand for environmental protection,high-modulus

recycled polyester industrial yarn is mainly used in automotive seat belts,

airbags, inside roof lining, seat covers and other automotive safety parts and interior in the automotive industry. Using recycled polyester as a raw material can assist automobile manufacturers in achieving the goal of sustainable development.
