Flame-retardant and Anti-melt- drop Polyester Fiber

Reasons for recommendation

With stable flame-retardant and high anti-melt-drop properties

obtained through the copolymerization modification, the products are

self-extinguishing from the fire, which can significantly reduce the rate

of flame spreading during a fire, and effectively reducing the secondary

damage to the human body during a fire.

Preparative technique

Flame-retardant and anti-melt-drop agents are introduced during the esterification process, and flame-retardant and anti-melt-drop polyester pellets are created through polycondensation and pelletizing, before the fibers are prepared using the melt spinning technique.

Features of fibers and finished products

Main Specifications

Filament: 83dtex/36f,83dtex/48f, 83dtex/72f, 111dtex/48f,

167dtex/48f, 333dtex/96fDTY

Relative Standards

Flame-retardant and anti-melt-drop pre-oriented dacron yarns

(Q/HYYJ 034-2024)

Flame-retardant and anti-melt-drop low-elasticity dacron yarns

(Q/HYYJ033-2024)

Properties of fibers and features of finished products

.Good flame-retardant(non-halogen phosphorus flame-retardant)

performance, with the limiting oxygen index >30%, no droplets during

combustion.

. Co-polymerized flame-retardant,long lasting flame-retardant effect,washable.

Performance indexes of flame-retardant and anti-melt-drop polyester fiber

Specifications	Breaking strength(cN/dtex)	Elongation at break(%)	Fabric composition (100% this fiber)
			Limiting oxygen index (%)	Smoldering and sustained combustion duration (s)	Damage length (mm)	Burning with or without dripping
167dtex/48f	2.77	21.50	Wrap:32.30Weft: 32.30	Wrap: 0Weft: 0	Wrap: 96Weft: 101	None

The downstream application guidance

Weaving: Can be blended with other flame-retardant fibers for knitted and woven fabrics.

Dyeing : The suggested dyeing temperature is 120~125℃ , and the heat setting temperature is 130~150℃.

Types of Fabric	Raw material ratio	Fiber specification	Properties of the product
Home textiles	100% flame-retardant and anti-melt-drop polyester fiber or blended with other flame-retardant fibers	333dtex/96f DTY333dtex/96f DTY	Used in the weaving of bottom and top yarns for curtains, with good drape and soft hand-feel fabrics
Automotive interiors	100% flame-retardant and anti-melt-drop polyester fiber or blended with other flame-retardant fibers	83dtex/48f FDY83dtex/48f FDY	Used in the weaving of bottom and top yarns for automotive interiors with long-lasting, durable and comfortable fabrics

Application of fibers

Home textiles：Curtain/Sofa fabric

Industrial textiles：Automotive interior

Q: What are the advantages of flame-retardant and anti-melt-drop

polyester fibers over conventional flame-retardant polyester fibers?

A: One of the flame-retardant mechanisms of conventional flame-retardant polyester fibers is to consume heat by melting droplets generated by the melting of fibers, thus slowing down the burning speed of fabrics. However, high-temperature melt droplets will cause serious harm to the human body. While flame-retardant and anti-melt-drop polyester fibers combined with specially developed synergistic

anti-melt-drop agents, which can further strengthen the flame-retardant effect and the durability of the fibers, greatly reducing the occurrence of secondary injuries,and effectively ensuring the safety of the human body. The fabrics are soft and comfortable, and can be widely used in automotive interiors, curtain fabrics and home textiles.
